Power Probe PP3 PP3CSRED

32.500 kr.

PP3CS CONTENTS

  • Power Probe 3 with standard 20 ft (6 m)
  •  Power Cable
  • 3 in (8 cm) Probe Tip
  • Battery Clip Set
  •  Instruction Manual/CD

Availability: In stock

SKU: PP3CSRED Category: Tag:

Introduction

The original Power Probe 3 uses a 20ft cable which attaches to the vehicle’s battery, allowing the user to perform an electrical test anywhere in, or around the vehicle. The PP3 is a Voltmeter and Continuity Tester, with Audible & Visual indicators along with two LED headlights to light up your work area. This circuit tester also supplies Battery Voltage or Ground to activate components. This powerful time-saver tool is perfect for every level of technician.

Power Probe 3

Features
DC Voltmeter Indicators provide active feedback
LED Lights
Bad Ground –Indicator
Short Circuit Indicator
Relay and Component Tester
Audible Monitoring of Electrical Signals

Power Probe 3

Specifications

– DC 0 – 70V + 1 digit

– P-P 0 – 70V

Frequency response of tone pass through

– 10Hz to greater than 10 Khz

PP display

– 15Hz Square Wave

– 35Hz Sine Wave

Power Probe Mode – Continuity to ground

– First level – display is enabled less than 20K

– Second level – green LED is enabled less than 2K

– & + Peak Detector Response

– Single event capture less than 200μs pulse width

– Repetitive events less than 1μs pulse width

Peak to Peak Mode

– 0 – 70V + 1 digit

– 4Hz to over 500kHz Square Wave input

– 4Hz to over 250kHz Sine Wave input

Threshold for PPAC/Audible passthrough

Circuit Breaker

8 amp thermal response – Manual reset

Typical Response

User Manual     Datasheet



Weight 0,633 kg
Dimensions 31 × 21 × 5 cm
