Power Probe
Power Probe PP3 PP3CSRED
32.500 kr.
PP3CS CONTENTS
- Power Probe 3 with standard 20 ft (6 m)
- Power Cable
- 3 in (8 cm) Probe Tip
- Battery Clip Set
- Instruction Manual/CD
Availability: In stock
Introduction
The original Power Probe 3 uses a 20ft cable which attaches to the vehicle’s battery, allowing the user to perform an electrical test anywhere in, or around the vehicle. The PP3 is a Voltmeter and Continuity Tester, with Audible & Visual indicators along with two LED headlights to light up your work area. This circuit tester also supplies Battery Voltage or Ground to activate components. This powerful time-saver tool is perfect for every level of technician.
| Features | |
| – | DC Voltmeter Indicators provide active feedback |
| – | LED Lights |
| – | Bad Ground –Indicator |
| – | Short Circuit Indicator |
| – | Relay and Component Tester |
| – | Audible Monitoring of Electrical Signals |
Specifications
– DC 0 – 70V + 1 digit
– P-P 0 – 70V
Frequency response of tone pass through
– 10Hz to greater than 10 Khz
PP display
– 15Hz Square Wave
– 35Hz Sine Wave
Power Probe Mode – Continuity to ground
– First level – display is enabled less than 20K
– Second level – green LED is enabled less than 2K
– & + Peak Detector Response
– Single event capture less than 200μs pulse width
– Repetitive events less than 1μs pulse width
Peak to Peak Mode
– 0 – 70V + 1 digit
– 4Hz to over 500kHz Square Wave input
– 4Hz to over 250kHz Sine Wave input
Threshold for PPAC/Audible passthrough
Circuit Breaker
8 amp thermal response – Manual reset
Typical Response
User Manual Datasheet
| Weight | 0,633 kg |
|---|---|
| Dimensions | 31 × 21 × 5 cm |
