About this item
Product Name – Bus bar terminal block 12v, these battery bus bar 12v
300A M10 Stud Busbar – This battery distribution block can handle max 300A continuous amperage at Max 300V AC or 48V DC voltage. battery terminal block includes – 6 x M10 (3/8″)terminal studs.
Round Corner Base – This 12v bus bar is unique round corner base design, which makes the marine bus bar unique and special, looks more extraordinary compared with others.
Special Design Cover – The exposed area of two side of this 12v power distribution block cover allows 180° wire lug installation, can meet a variety kinds of install methods of end terminals.
Application – This 300A bus bar will have better performance in high current systems. The package includes one positive and one ground distribution block, suitable for automotive, car, marine boat, etc.
Spec
| Part NO | BB300-T6M10/ |
| Connection Type | Red for Positive Black for Negative |
| Terminal Studs | 6 x M10 (3/8″) |
| Base & Cover Material | Nylon |
| Bus Material | Copper |
| Terminals Material | Stainless Steel |
| Max Voltage | 48V DC |
| Max Continuous Amperage | 300 AMP |
| Overall Dimension | 180mm x 38mm x 46mm (LxWxH) |
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Colors | Rautt, Svart |
