KH180 Series Automotive Relay Details
-
Easy Installation
The product is equipped with terminals, washers, battery clip accessories and locks, making installation more simple and convenient.
-
Stable Performance
The 12v relay uses high-quality alloy terminals, and the internal contacts are silver-plated to ensure the flow and stability of current.
-
Safety Protection
The relay kit is made of high-grade flame retardant materials to protect the safety of equipment and people.
-
Wide Application
The large coil capacity makes it easy to handle those high-current applications. It is suitable for cars, split charging, and various automotive applications.
KH180 Series
| KH180-200-12 | 200A, 12VDC (15.6V Max), 4-Pin, Normal Open |
KH180 Series Relay Datasheet
| Nominal Voltage (VDC) | 12V |
| Max Applicable Voltage (VDC) | 15.6V |
| Switching Current | 200A |
| Temperature Range | -40~+90°C |
| Contact Material | AgSnO12 |
| Contact Form | Normal Open |
| Operate Time | 15ms |
| Release Time | 10ms |
| Weight | 0,093 kg |
|---|---|
| Dimensions | 7,5 × 4 × 4 cm |
